PET plastic steel strapping equipment single screw PET strapping production line plastic extruder
FEATURE DESCRIPTION OF PET PLASTIC STEEL BELT EQUIPMET
PET plastic steel belt equipment
PET plastic steel belt equipment is a high-speed, intelligent and environmentally friendly plastic equipment with the following advantages:
1. Raw materials:
PET plastic steel belt can use raw materials: bottle flakes or crushed materials or thickening granular materials
Bottle flakes: waste mineral water, Sprite, Coke and other bottle flakes as raw materials, which are crushed, cleaned and dried.
Crushed materials: finished PET plastic steel belt is crushed and screened, cleaned and dried;
Viscosity granular materials: PET crushed materials are processed, cleaned and thickened granular materials
RAW MATERIALS
--------100% PET bottle flakes (hot water washing)
----------100% PET shreds (hot water washing)
FEATURES OF PET PLASTIC STEEL BELT PRODUCTION LINE
Screw--------
The screw of the PET plastic steel belt production line is made of 38CrMoALA material, a special screw for extruders, with good plasticization and uniform extrusion, ensuring the durability and long-term performance of the equipment
EXTRUSION PARAMETERS TABLE
| Model | PET-2 | PET-3 | PET-4 | PET-6 | PET-8 |
| Raw materials | 100% Bottle flakes/crushed materials |
| Number of tapes | 2 | 3 | 4 | 6 | 8 |
| Width (mm) | 9-32 |
| Width (mm) | 0.4-1.2 |
| Maximum line speed(m/min) | ≧150 | ≧150 | ≧150 | ≧150 | ≧150 |
| PLC control system | PLC | PLC | PLC | PLC | PLC |
| Screw Model | 90 | 100 | 125 | 150 | 180 |
| Reducer model | 200 | 250 | 280 | 315 | 350 |
| Dryer tank | 3000L | 4000L | 5000L | 6000L | 6000L |
| Dehumidifier | 1000 | 1000 | 2000 | 3000 | 3500 |
| Metering Pumps | 100CC | 100CC | 100CC | 100CC | 100CC |
| Screen Changer | Single cylinder |
| Winding machine | Automatic winding/ Semi-automatic winding |
| Production capacity /24 H | 5-6T | 7-8T | 10-12T | 12-15T | 18-20T |
CHEMICAL FIBER FILTER
Special chemical fiber filter for PET plastic steel belt, which meets the filtration accuracy required by the product. Effective exhaust procedure prevents outside air from entering the melt when changing the screen. Simple operation, high reliability, short material retention time, no leakage, small pressure loss, and smooth flow channel.
Finished PET plastic steel belt
After-sales service
PET plastic steel strap production line provides comprehensive technical support and services. We have an experienced technical team that can quickly provide a variety of services, including:
Pre-sales:
1. Layout of PET plastic steel strap production line .
2. Analysis of finished product manufacturing costs of PET plastic steel belt equipment .
3. Analysis of raw materials used in PET plastic steel strap production line .
After-sales service:
1. Waterway diagram, circuit diagram, pipeline connection drawings, etc. of PET plastic steel strap production line .
2. Installation, commissioning and training of PET plastic steel strap production line .
3. Maintenance service of PET plastic steel strap production line .
4. Regular maintenance and repair
5. Fault diagnosis
6. Software update and upgrade
7. Spare parts and accessories
8. Training and technical consultation
FAQ:
Q: What is the voltage of the PET plastic steel belt equipment ?
A: 380V/50HZ, three-phase (customization supported)
Q: What is the extrusion capacity of the PET plastic steel belt equipment?
A: Different models have different extrusion capacities, with capacities ranging from 150-600KG/H
Q: What is the producible width of the PET plastic steel belt equipment ?
A: 9-32mm
Q: Can the PET plastic steel belt equipment be customized?
A: Customization supported
Q: Where does the PET plastic steel belt equipment come from?
A: China.
Q: What are the certifications for the PET plastic steel belt equipment ?
A: ISO CEO certification.
Q: What is the minimum order quantity for the PET plastic steel belt equipment ?
A: 1 set
Q: What is the weight of the PET plastic steel belt equipment ?
20T, 40GP container * 3PCS
